Fluorescence microscopes Professional Line OBN 141

Kern & Sohn GmbH (10649)

Fluorescence microscopes Professional Line OBN 141
This series has a professional Koehler illumination unit with an adjustable field diaphragm, with infinity optical system. A variety of modular systems, such as a swing-out condenser, various eyepieces, objectives, color filters, phase contrast units, a dark field condenser, a simple polarising unit, butterfly tube, through to complete fluorescence units are optionally available. A C-mount adapter is required to connect a camera (optional).

-Tube 30° inclined, 360° rotatable
-Diopter adjustment: both-sided
-Objective quality: Infinity Plan
-Coaxial pre-and fine focussing
-For translucent, thin, low-contrast, challenging samples (e.g. immunofluorescence, FISH, DAPI staining, etc.)
-Centering and height-adjustable 1.25 Abbe condenser with adjustable aperture diaphragm
-Incl. centering objective for fluorescence adjustment
-3 W LED transmitted illumination unit and 5 W LED epi-fluorescence incident illumination unit
-6-position filter wheel with B/G fluorescence filter

Scope of supply: microscope, centring objective, dust Cover, eyepiece rubber caps, manual instruction

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4676278	OBN 141	Kern & Sohn GmbH		220	490	1	OBN 141	13	530	Abbe 1,25					7558.82 EU

Fluorescence microscopes Professional Line OBN 142

Kern & Sohn GmbH (935351)

Fluorescence microscopes Professional Line OBN 142
This series has a professional Koehler illumination unit with an adjustable field diaphragm, with infinity optical system. A variety of modular systems, such as a swing-out condenser, various eyepieces, objectives, color filters, phase contrast units, a dark field condenser, a simple polarising unit, butterfly tube, through to complete fluorescence units are optionally available. A C-mount adapter is required to connect a camera (optional).

-Tube 30° inclined, 360° rotatable
-Diopter adjustment: both-sided
-Objective quality: Infinity Plan
-Coaxial pre-and fine focussing
-For translucent, thin, low-contrast, challenging samples (e.g. immunofluorescence, FISH, DAPI staining, etc.)
-Centering and height-adjustable 1.25 Abbe condenser with adjustable aperture diaphragm
-Incl. centering objective for fluorescence adjustment
-3 W LED transmitted illumination unit and 5 W LED epi-fluorescence incident illumination unit
-6-position filter wheel with a B/G/UV/V fluorescence filter

Scope of supply: microscope, centring objective, dust cover, eyepiece rubber caps, manual instruction

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4716239	OBN 142	Kern & Sohn GmbH		220	490	1	OBN 142	13	530	Abbe 1,25					9588.24 EU

Light microscopes Professional Line OBN 13

Kern & Sohn GmbH (10638)

Light microscopes Professional Line OBN 13
This series has a professional Koehler illumination unit with an adjustable field diaphragm, with infinity optical system. A variety of modular systems, such as a swing-out condenser, various eyepieces, objectives, color filters, phase contrast units, a dark field condenser, a simple polarising unit, butterfly tube, through to complete fluorescence units are optionally available. A C-mount adapter is required to connect a camera (optional).

-Tube 30° inclined, 360° rotatable
-Diopter adjustment: both-sided
-Objective quality: Infinity Plan
-Coaxial pre-and fine focussing
-Centering and height-adjustable 1.25 Abbe condenser with adjustable aperture diaphragm
-OBN 132: Halogen illumination 20 W, including blue color filter
-OBN 135: LED illumination 3 W

Scope of supply: microscope, centring eyepiece, dust cover, eyepiece rubber caps, manual instruction

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4657662	OBN 132	Kern & Sohn GmbH		200	400	1	OBN 132	9	390	Abbe 1,25					2367.65 EU
4666527	OBN 135	Kern & Sohn GmbH		200	395	1	OBN 135	9	390	Abbe 1,25					2483.82 EU

Light microscopes Professional Line OBN 147

Kern & Sohn GmbH (935302)

Light microscopes Professional Line OBN 147
This series has a professional Koehler illumination unit with an adjustable field diaphragm, with infinity optical system. A variety of modular systems, such as a swing-out condenser, various eyepieces, objectives, color filters, phase contrast units, a dark field condenser, a simple polarising unit, butterfly tube, through to complete fluorescence units are optionally available. A C-mount adapter is required to connect a camera (optional).

-Tube 30° inclined, 360° rotatable
-Diopter adjustment: both-sided
-Objective quality: Infinity Plan
-Coaxial pre-and fine focussing
-For translucent, thin, low-contrast, challenging samples (e.g. immunofluorescence, FISH, DAPI staining, etc.)
-Centering and height-adjustable 1.25 Abbe condenser with adjustable aperture diaphragm
-Incl. centering objective for fluorescence adjustment
-20 W halogen transmitted illumination unit and 100 W epi-fluorescent incident illumination unit
-6-position filter wheel with B/G fluorescence filter

Scope of supply: microscope, centring objective, dust Cover, eyepiece rubber caps, manual instruction

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4657663	OBN 147	Kern & Sohn GmbH		220	490	1	OBN 147	13	530	Abbe 1,25					7698.24 EU

Phase contrast microscopes OBL 14/15

Kern & Sohn GmbH (708637)

Phase contrast microscopes OBL 14/15
For extremely translucent, thin, low-contrast, challenging samples (e.g. living mammal cells, bacteria, tissue) with phase contrast.

-Infinity optical system
-Tube 30° inclined, 360° rotatable
-Diopter adjustment at one eyepiece tube
-Coaxial pre-and fine focussing
-Abbe N.A. 1,25 precentered, for bright field and phase contrast
-Lightfield diaphragm
-20 W halogen or 3 W LED illumination

Scope of supply: Microscope, protective dust cover, eye cups, user instructions

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4691073	OBL 146	Kern & Sohn GmbH		200	380	1	OBL 146	6.7	395	Abbe N.A. 1,25	EU				2323.53 EU
6491772	OBL 156	Kern & Sohn GmbH		200	380	1	OBL 156	6.7	395	Abbe N.A. 1,25	EU				2558.24 EU

Phase contrast microscopes professional line OBN 15

Kern & Sohn GmbH (701794)

Phase contrast microscopes professional line OBN 15
This series has a professional Koehler illumination unit with an adjustable field diaphragm, with infinity optical system. A variety of modular systems, such as a swing-out condenser, various eyepieces, objectives, color filters, phase contrast units, a dark field condenser, a simple polarising unit, butterfly tube, through to complete fluorescence units are optionally available. A C-mount adapter is required to connect a camera (optional).

-Tube 30° inclined, 360° rotatable
-Diopter adjustment: both-sided
-Objective quality: Infinity Plan
-Coaxial pre-and fine focussing
-Centre and height adjustable PH universal rotary condenser, aperture diaphragm and field diaphragm
-Coaxial coarse and fine focusing
-OBN 158: Halogen lighting 20 W
-OBN 159: LED lighting 3 W

Scope of supply: Phase contrast microscope, centring eyepiece, protective dust cover, eye cups, user manual

PN	Manuf. PN	Supplier		Depth~mm	Height~mm	PK	Type	Weight~kg	Width~mm	Condenser	Plug type	Rated capacity		General	Price	Quantity	Status	Add
4666528	OBN 158	Kern & Sohn GmbH		200	400	1	OBN 158	9	390						4371.92 EU
6491267	OBN 159	Kern & Sohn GmbH		200	400	1	OBN 159	9	390						4398.31 EU
