Real-time PCR-system Eco 48

Cole-Parmer Instrument (422057)

Real-time PCR-system Eco 48
High specification, economically priced real-time thermocycler. The Eco 48 system has a unique high thermal block uniformity (± 0.1°C). This uniformity as well as validated sample volumes of down to 5 µl enable an optimized reaction run time for 40 cycl... Real-time PCR-system Eco 48
High specification, economically priced real-time thermocycler. The Eco 48 system has a unique high thermal block uniformity (± 0.1°C). This uniformity as well as validated sample volumes of down to 5 µl enable an optimized reaction run time for 40 cycles down to only 15 minutes. The uniform temperature across the plate is achieved with a unique heating and cooling system that quickly enables a uniform temperature of ± 0.1°C in every well of the block within a fraction of a second of reaching each well temperature. This high uniformity eliminates the need for triplicates which reduces reagent running costs. Eco 48 accommodates a unique and economical 48-well PCR plate, the size of which is only 1/8 the size of a standard 96-well plate. The well format mirrors a 384-well plate therefore allowing the use of a 16-channel micropipette. The small plate cuts reagent costs in half whilst still producing a strong fluorescent signal. Applications include e.g. absolute and relative quantification, Allelic Discrimination and High Resolution Melt.

Features:

-Validated volume per well: 5 to 20 µl
-High temperature uniformity of ± 0.1°C across the whole block instantly after every temperature change
-40 cycles in 40 minutes before optimization, and down to only 15 minutes when optimized
-Genotype in 4 minutes with over 99% accuracy
-Patented "Adaptive LED Control" minimizes optical artifacts and prevents premature detector saturation
-Dual LED excitation (452 nm to 486 nm and 542 nm to 582 nm)
-4 emission filters (505 nm to 545 nm, 562 nm to 596 nm, 604 nm to 644 nm, 665 nm to 705 nm)
-Data is always collected in all four filters for all wells
-Distinguishes 5000 and 10000 template copies with 99 percent confidence

Additional features:

-48-well block
-MIQE compliant
-400 analyte specific qPCR reagent kits available
-No calibration required
-Calibrated dyes: SYBR®, FAMTM, HEXTM, ROXTM, Cy®5.
-Additional dyes within the filter wavelength range are supported with no additional calibration required
-Unlimited software licence
-2 years warranty

Scope of supply:
Real-time PCR-system Eco 48, EcoControl and EcoStudy software, USB stick, 50 plates, 50 plate seals, power and Ethernet cable
Specifications
Temperature range: 30 to 100°C
Temperature stability: ±0.1°C
Temperature uniformity: ±0.1°C within 1sec
Average ramp rate: 5.5°C/sec
Dimensions (W x D x H): 345 x 310 x 320mm
Weight: 13.6kg

PN	Manuf. PN	Supplier		PK	Type									General	Price	Quantity	Status	Add
6320624	93947-00	Cole-Parmer Instrument		1	Eco 48										29472.55 EU

1 items found Page 1 of 1
